Cushion Gasket_IDCCD Series

Specifications

Item Unit Spec. Reference Color - Gray   Pore count ppi 80 - Thickness Mm ±20% Standard Size 0.3, 0.5, 0.7, 1.0, 1.5, 2.0, 3.0 Width Mm 500 - Surface Resistance Ω/sq Max. 0.1 MIL-DTL-83528C/Foam Side Contact Resistance Ω/in2 Max. 0.1 1kg Pressure Shielding Effectiveness dB Min. 70 ASTM D 4935 Adhesive Strength gf/25mm Min. 1000 KS T 1028 (180° peel) Temp. Range ℃ -10 ~ 80 -
