| IDCF series |
|
|
|
SMT Gasket is a conductive gasket using for circuit ground SMT to reduce the electrical/ electronic malfunction and its EMI noise.
Existing EMI shielding gasket are produced in wrapping the foam with conductive fabric but it does not have high temperture resistance.
SMT gasket have the excellent electrical conducivity, high heat resistance and SMT mountable characteristics for automatic soldering procedure.
This product is patented for unquie technology.
|
|
|
|
IDFC is recently developed for SMD finger Strip for use PCB featuring excellent resilience and electrical properties.
|
  |
|
|
| Specifications |
| Content |
Properties |
| SC |
NC |
| Temp. Rating |
-50~120 |
-50~120 |
| Volume Resistivity (Ω.cm) |
Max. 0.02 |
Max. 0.1 |
| Specific Gravity (at 25°C) |
3.7 ± 0.3 |
2.5 ± 0.3 |
| Hardness (Shore A) |
65 ± 5 |
50 ± 5 |
| Shielding Effectiveness (dB) |
Min. 60 |
Min. 40 |
|
